Hima Safety Systems F 3222 (0507)

F 3222 (0507)All rights reserved. Equipment subject to change without notice: 1/2HIMA Paul Hildebrandt GmbH + Co KG, P.O. Box 1261, 68777 BrühlF 3222F 3222: 8-channel input modulefor proximity switches according to EN 60947-5-6 (NAMUR)with safety isolation,with feeding of the proximity switchesBlock diagramTruth table:Switching point 1.65 mA ± 0.2 mASwitching current difference approx. 0.3 mASwitching time approx. 10 msSensor supply 7.7...9 VSpace requirement 4 TEOperating data 5 V DC / 40 mA24 V DC / 75 mAZ7108/3222/...Frontcable plugF 3222 (0507)2/2Lead marking cable plugZ 7108 / 3222 / C..Function tableChannel Connection Colour12345678d2d4d6d8d10d12d14d16d18d20d22d24d26d28d30d32WHBNGNYEGYPKBURDBKVTWHBNWHGNWHYEWHGYWHPKWHBUCableLiYY 16 x 0.5 mm2Inputd4 - d2..D32 - d30Input currentI inmA ELEDz4..z30Control channel1..8- +- +> 2.1< 1.2H signalL signal
